'cnc router machines'

Numac Hitech offers a range of CNC router machines, including models with double spindles, designed to cater to various material processing needs. Below are the technical specifications for their 6090, 1325, and 1530 double spindle CNC router machines: 1. NH6090 2-Spindle CNC Aluminum Router Machine Working Area: 600 x 900 mm Spindle Power: 1-3 kW Spindle Type: Double Spindle Automatic Grade: Automatic Application: Engraving and routing of aluminum, brass, and copper Certification: CE Certified Voltage: 380V Weight: 100-1000 kg Warranty: 1 Year This machine features an advanced mechanism, is easy to maintain, and offers high productivity. NUMACHITECH.COM 2. 1325 CNC Router Machine Working Area: 1300 x 2500 mm Spindle Power Options: 3.5 kW, 4.5 kW, or 6 kW Spindle Speed: 0-18,000 RPM or 0-24,000 RPM Spindle Head Type: Single Spindle Suitable Materials: Wood, MDF, ACP, WPC, Corian, Acrylic Features: Equipped with Easy Servo Motor and Drive (Leadshine) This model is designed for efficient processing of various materials with high precision. NUMACHITECH.COM 3. NH1530 CNC Router Machine Working Area: 1500 x 3000 mm Spindle Power: Customizable based on requirements Spindle Head Type: Single Spindle Suitable Materials: Wood, Acrylic, Plastic, Aluminum, Copper, Brass, MDF, Corian Voltage: 440V Features: Advanced mechanism, high productivity, and low maintenance This machine is versatile and suitable for a wide range of material processing applications. NUMACHITECH.COM For more detailed information or specific inquiries, you can contact Numac Hitech directly: Address: 16-1, Bombay Cotton Mill Estate, Dattaram Lad Path, Kalachowki, Mumbai - 400033, Maharashtra, India Phone: +91-9821026895, +91-8655080774 Email: numachitech@gmail.com

Numac Hitech offers a range of CNC router machines tailored for various applications. Below are the technical specifications for some of their models: 1. 1325 CNC Router Machine Working Area: 1300 x 2500 mm Spindle Power: Options of 3.5 kW, 4.5 kW, or 6 kW Spindle Speed: 18,000 RPM or 24,000 RPM Drive Mechanism: German imported ball screw Motion Positioning Accuracy: ±0.02/300 mm Repositioning Accuracy: ±0.04 mm Maximum Motion Speed: 20,000 mm/min Maximum Working Speed: 18,000 mm/min Engraving Tools: Ø3.175 mm, Ø4 mm, Ø6.00 mm Operating Voltage: AC 220V/50/60Hz Operating System: DSP off-line control system Software Compatibility: Type3, Wentai, ArtCAM Frame Material: Cast iron/aluminum wholly NUMACHITECH.COM 2. 3D Wood CNC Router Machine Brand Name: Numac Hitech Application: Woodworking, acrylic, 2D & 3D work Voltage: 230V AC Features: Advanced mechanism Low maintenance High productivity NUMACHITECH.COM 3. CNC Aluminum Router Machine Rated Power: 1-3 kW Automatic Grade: Automatic Application: Engraving & routing of aluminum, brass, copper Certification: CE Certified Voltage: 380V Features: Advanced mechanism Easy to maintain High productivity NUMACHITECH.COM 4. NH1530 CNC Router Machine Application: Wood, acrylic, plastic, aluminum, copper, brass, MDF, Corian materials Voltage: 440V Type: CNC Router Machine Driven Type: Electric, mechanical Color Options: Black, yellow NUMACHITECH.COM For more detailed information or specific inquiries, you can contact Numac Hitech directly: Address: 16-1, Bombay Cotton Mill Estate, Dattaram Lad Path, Kalachowki, Mumbai - 400033, Maharashtra, India Phone: +91-9821026895, +91-8655080774 Email: numachitech@gmail.com

The Numac Hitech engraving CNC router is a machine designed for precision engraving, carving, and cutting of various materials. While specific details might vary depending on the model and configuration, here are the typical specifications you can expect for such machines: General Specifications: Machine Type: CNC engraving router (also used for milling, carving, and cutting) Control System: Typically uses a numerical control (NC) system, compatible with G-code for precise movement control. Frame: Heavy-duty steel frame or welded steel construction for rigidity and stability. Drive Motors: High-performance servo motors or stepper motors for precise movement. Work Area: Worktable Size: Varies by model but typically ranges from 600mm x 600mm to 1500mm x 3000mm. Z-Axis Travel: Often around 100mm to 300mm, allowing for various material thicknesses. Max Cutting Depth: Typically up to 200mm, depending on the machine. Spindle and Cutting: Spindle Power: Spindle power can range from 1.5 kW to 5 kW, with some models offering higher power for harder materials. Spindle Speed: Speeds generally range from 12,000 to 24,000 RPM. Tool Type: Uses high-speed rotary tools such as engraving bits, routers, and cutters, depending on the material and the precision required. Features: CNC Control System: Commonly equipped with NC Studio or DSP controllers, or even Mach3 software. Precision: High precision, with typical positioning accuracy of 0.01mm and repeatability around 0.005mm. Table Surface: Can include options for vacuum hold-down or T-slot for securing workpieces. Cooling System: Equipped with a water cooling or air cooling system for the spindle to ensure consistent performance. Dust Collection: Some machines come with a dust extraction system to keep the workspace clean during engraving.

The Numac Hitech engraving CNC router is a machine designed for precision engraving, carving, and cutting of various materials. While specific details might vary depending on the model and configuration, here are the typical specifications you can expect for such machines: General Specifications: Machine Type: CNC engraving router (also used for milling, carving, and cutting) Control System: Typically uses a numerical control (NC) system, compatible with G-code for precise movement control. Frame: Heavy-duty steel frame or welded steel construction for rigidity and stability. Drive Motors: High-performance servo motors or stepper motors for precise movement. Work Area: Worktable Size: Varies by model but typically ranges from 600mm x 600mm to 1500mm x 3000mm. Z-Axis Travel: Often around 100mm to 300mm, allowing for various material thicknesses. Max Cutting Depth: Typically up to 200mm, depending on the machine. Spindle and Cutting: Spindle Power: Spindle power can range from 1.5 kW to 5 kW, with some models offering higher power for harder materials. Spindle Speed: Speeds generally range from 12,000 to 24,000 RPM. Tool Type: Uses high-speed rotary tools such as engraving bits, routers, and cutters, depending on the material and the precision required. Features: CNC Control System: Commonly equipped with NC Studio or DSP controllers, or even Mach3 software. Precision: High precision, with typical positioning accuracy of 0.01mm and repeatability around 0.005mm. Table Surface: Can include options for vacuum hold-down or T-slot for securing workpieces. Cooling System: Equipped with a water cooling or air cooling system for the spindle to ensure consistent performance. Dust Collection: Some machines come with a dust extraction system to keep the workspace clean during engraving.

A PCB CNC drilling machine is designed for precise drilling and routing of printed circuit boards (PCBs). These machines are essential for creating the holes needed for component leads and vias in PCBs. Below are the typical technical specifications of a PCB CNC drilling machine: ### *Technical Specifications: * 1. *Working Area:* - *X, Y Travel:* Common sizes include: - *600MM X 900MM X 80MM - Larger machines may have work areas of 600 mm x 400 mm or more. - *Z-Axis Travel:* Typically 50 mm to 100 mm 2. *Spindle:* - *Spindle Power:* 0.8 kW to 2.2 kW (depending on the model) - *Spindle Speed:* 20,000 to 60,000 RPM, high-speed spindles are preferred for fine drilling - *Collet Size:* Typically ER8, ER11, or custom collets for PCB drill bits 3. *Positioning Accuracy:* - *Positioning Accuracy:* ±0.01 mm - *Repeatability:* ±0.005 mm 4. *Drilling Capability:* - *Drill Bit Diameter:* Typically ranges from 0.5 mm to 3.2 mm - *Max Drilling Speed:* High-speed drilling with rates up to 120 hits per minute, depending on machine and material 5. *Control System:* - *Controller:* PC-based or DSP control systems - *Software Compatibility:* Compatible with Gerber files and CAD/CAM software specific to PCB design (e.g., Altium Designer, Eagle, KiCad) - *File Formats Supported:* G-code, Excellon, NC Drill, etc. 6. *Drive System:* - *Motors:* Precision stepper motors or servo motors - *Transmission:* Ball screw transmission for smooth and accurate movement - *Guide Rails:* Linear guide rails for high precision 7. *Power Supply:* - *Voltage:* Typically 220V/50Hz, though smaller machines may operate at 110V - *Power Consumption:* Ranges from 1 kW to 3 kW depending on the machine's spindle power and additional features 8. *Table Structure:* - *Table Surface:* Flat surface, often with a vacuum table or fixture system to secure the PCB - *Fixture System:* Adjustable clamps or vacuum bed for securing PCB during drilling 9. *Tool Cooling and Dust Extraction:* - *Cooling Method:* Air cooling or mist cooling system for the spindle and drill bits - *Dust Collection:* Integrated dust extraction system to remove debris and maintain a clean working environment 10. *Machine Dimensions and Weight:* - *Dimensions:* Compact design, typically around 800 mm x 600 mm x 600 mm, though larger models may be bigger - *Weight:* Generally ranges from 100 kg to 300 kg, depending on the build and features 11. *Optional Features:* - *Automatic Tool Changer (ATC):* For changing drill bits automatically during the process - *Vision System:* For alignment and inspection, ensuring precise drilling - *Router Capability:* Some machines also offer routing capabilities for cutting out the PCB outline - *Multi-Head Design:* Allows for simultaneous drilling of multiple holes 12. *Safety Features:* - *Emergency Stop Button:* For immediate shutdown in case of emergency - *Cover/Enclosure:* To protect the operator from debris and noise These specifications can vary based on the manufacturer and specific model, so it's important to verify the exact specs to match your production needs. PCB CNC drilling machines are critical for high-precision work, and selecting the right one depends on the complexity and volume of your PCB production.

A stone CNC router machine is designed specifically for engraving, cutting, and shaping various types of stone, including marble, granite, quartz, and other hard materials. Below are the typical technical specifications of a stone CNC router machine: ### *Technical Specifications:* 1. *Working Area:* - *X, Y, Z Travel:* Varies widely, common sizes include: - *1300 mm x 2500 mm x 200 mm (4.3 ft x 8.2 ft x 7.9 in)* - *1500 mm x 3000 mm x 300 mm (4.9 ft x 9.8 ft x 11.8 in)* - Larger sizes available depending on the machine - *Table Size:* Similar to the X, Y dimensions 2. *Spindle:* - *Spindle Power:* 5.5 kW to 9.0 kW or more, depending on the model and material requirements - *Spindle Speed:* 0-24,000 RPM - *Cooling System:* Water-cooled spindle for continuous operation - *Collet Size:* ER20 or ER25, depending on spindle type 3. *Positioning Accuracy:* - *Positioning Accuracy:* ±0.05 mm - *Repeatability:* ±0.02 mm 4. *Transmission:* - *X, Y Axis Transmission:* Helical rack and pinion for high precision - *Z Axis Transmission:* Ball screw transmission for stable and precise movement - *Guide Rails:* Heavy-duty linear guide rails (often Hiwin or similar) 5. *Control System:* - *Controller:* NC Studio, DSP, Syntec, or Mach3 control systems - *Software Compatibility:* Compatible with CAD/CAM software like ArtCAM, Type3, Alphacam, etc. - *File Formats Supported:* G-code, HPGL, U00, MMG, etc. 6. *Drive System:* - *Motors:* Stepper motors or servo motors, depending on the model - *Drivers:* High-torque drivers for stability and power 7. *Power Supply:* - *Voltage:* 380V/50Hz for industrial machines (can vary by region) - *Power Consumption:* Typically ranges from 7 kW to 15 kW depending on the machine's spindle power and additional features 8. *Table Structure:* - *Table Surface:* T-slot table with clamps for securing stone slabs - *Bed Structure:* Heavy-duty steel frame for vibration reduction and durability 9. *Tool Cooling System:* - *Cooling Method:* Water circulation system to cool the tool during stone cutting - *Water Pump:* Industrial-grade water pump included for efficient cooling 10. *Dust and Water Management:* - *Water Spray System:* Integrated water spray to minimize dust and cool the cutting area - *Dust Collection:* Optional dust collection system for dry processing 11. *Machine Dimensions and Weight:* - *Machine Dimensions:* Varies depending on working area; typically large and heavy - *Weight:* Ranges from 1,500 kg to 3,500 kg (or more) depending on the size and structure of the machine 12. *Optional Features:* - *Rotary Axis:* For 3D engraving and sculpting of cylindrical objects - *Automatic Tool Changer (ATC):* For efficient tool switching during complex jobs - *Vacuum Table:* For securing thin or delicate stone materials - *4th/5th Axis:* For more complex, multi-dimensional cutting and engraving These specifications can vary depending on the manufacturer and specific model, so it's important to verify the exact specs when selecting a stone CNC router machine for your specific needs.

A stone CNC router machine is designed specifically for engraving, cutting, and shaping various types of stone, including marble, granite, quartz, and other hard materials. Below are the typical technical specifications of a stone CNC router machine: ### *Technical Specifications:* 1. *Working Area:* - *X, Y, Z Travel:* Varies widely, common sizes include: - *1300 mm x 2500 mm x 200 mm (4.3 ft x 8.2 ft x 7.9 in)* - *1500 mm x 3000 mm x 300 mm (4.9 ft x 9.8 ft x 11.8 in)* - Larger sizes available depending on the machine - *Table Size:* Similar to the X, Y dimensions 2. *Spindle:* - *Spindle Power:* 5.5 kW to 9.0 kW or more, depending on the model and material requirements - *Spindle Speed:* 0-24,000 RPM - *Cooling System:* Water-cooled spindle for continuous operation - *Collet Size:* ER20 or ER25, depending on spindle type 3. *Positioning Accuracy:* - *Positioning Accuracy:* ±0.05 mm - *Repeatability:* ±0.02 mm 4. *Transmission:* - *X, Y Axis Transmission:* Helical rack and pinion for high precision - *Z Axis Transmission:* Ball screw transmission for stable and precise movement - *Guide Rails:* Heavy-duty linear guide rails (often Hiwin or similar) 5. *Control System:* - *Controller:* NC Studio, DSP, Syntec, or Mach3 control systems - *Software Compatibility:* Compatible with CAD/CAM software like ArtCAM, Type3, Alphacam, etc. - *File Formats Supported:* G-code, HPGL, U00, MMG, etc. 6. *Drive System:* - *Motors:* Stepper motors or servo motors, depending on the model - *Drivers:* High-torque drivers for stability and power 7. *Power Supply:* - *Voltage:* 380V/50Hz for industrial machines (can vary by region) - *Power Consumption:* Typically ranges from 7 kW to 15 kW depending on the machine's spindle power and additional features 8. *Table Structure:* - *Table Surface:* T-slot table with clamps for securing stone slabs - *Bed Structure:* Heavy-duty steel frame for vibration reduction and durability 9. *Tool Cooling System:* - *Cooling Method:* Water circulation system to cool the tool during stone cutting - *Water Pump:* Industrial-grade water pump included for efficient cooling 10. *Dust and Water Management:* - *Water Spray System:* Integrated water spray to minimize dust and cool the cutting area - *Dust Collection:* Optional dust collection system for dry processing 11. *Machine Dimensions and Weight:* - *Machine Dimensions:* Varies depending on working area; typically large and heavy - *Weight:* Ranges from 1,500 kg to 3,500 kg (or more) depending on the size and structure of the machine 12. *Optional Features:* - *Rotary Axis:* For 3D engraving and sculpting of cylindrical objects - *Automatic Tool Changer (ATC):* For efficient tool switching during complex jobs - *Vacuum Table:* For securing thin or delicate stone materials - *4th/5th Axis:* For more complex, multi-dimensional cutting and engraving These specifications can vary depending on the manufacturer and specific model, so it's important to verify the exact specs when selecting a stone CNC router machine for your specific needs.

A CNC router with a vacuum table is designed to hold materials securely in place using suction, which is particularly useful for cutting, milling, or routing sheet materials. Here’s a rundown of the key features, benefits, and considerations for such a machine: Key Features: Vacuum Table: Suction Power: The vacuum table uses a high-power vacuum pump to create suction that holds the material firmly in place. This is especially useful for thin or large sheets that might otherwise be difficult to clamp. Grid Pattern: The table often features a grid of holes or channels to distribute the suction evenly across the surface. This helps in securing materials of varying sizes and shapes. Material Handling: Quick Setup: Vacuum tables allow for quick and easy material changes, which improves efficiency in production. Versatility: Suitable for various materials including wood, acrylic, MDF, and some composites. Precision and Stability: Even Pressure: The vacuum table provides consistent pressure across the material, which helps in achieving precise cuts and reducing material movement. Reduced Vibration: The secure holding reduces vibrations, leading to higher accuracy and better surface finishes. Software and Control: Integration: Often integrated with the CNC router’s control system to automatically manage the vacuum pump during operations. User Interface: Typically comes with an intuitive interface for ease of operation and setup. Benefits: Improved Accuracy: Stable Material: The secure hold of the vacuum table minimizes material movement, which helps in achieving high precision in cutting and milling. Efficient Workflow: Faster Setup: Easier and faster material loading and unloading compared to traditional clamping methods. Flexibility: Suitable for both small and large sheets, as well as irregularly shaped materials. Reduced Waste: Minimized Defects: Fewer issues with material shifting or warping, leading to less material waste and fewer defective parts. Considerations: Vacuum System Maintenance: Pump Care: Regular maintenance of the vacuum pump is required to ensure consistent suction power and performance. Table Surface: The vacuum table surface needs to be kept clean and in good condition to maintain optimal suction. Power Requirements: Electrical Needs: The vacuum pump requires a significant amount of power, so ensure your workshop can accommodate this. Size and Layout: Table Size: Choose a vacuum table size that matches your typical material dimensions and project needs. Table Configuration: Some tables have customizable or modular grid patterns, which can be adjusted based on your specific requirements. Cost: Investment: Machines with vacuum tables can be more expensive than those without, but they offer significant advantages in terms of efficiency and precision.

Product Details Certification CE Certified Voltage 380V Type CNC Aluminum Router Machine Weight 100-1000kg Warranty 1 Year Product Code NH6090 2SPINDLE To guard our complete range of goods from exterior causes that can be damaging, we have a high-tech packing unit armed with the newest safe packaging technologies and supplies. We carry out the quality examinations only under the vigil supervision of the quality auditors. Features : Advanced mechanishm Easy to maintain High productivity A CNC aluminum router machine is designed specifically for cutting, milling, and machining aluminum and other metals with high precision. These machines are robust and capable of handling the unique properties of aluminum, such as its softness and tendency to produce chips. Here are some key features and considerations: Key Features: Spindle Power and Speed: High-RPM Spindle: Aluminum machining requires high spindle speeds to effectively cut through the material. Look for machines with spindles capable of reaching high RPMs (usually 10,000 RPM or more). Cooling System: Some machines have built-in cooling systems or provisions for external cooling to manage heat during machining. Precision and Accuracy: Linear Guides and Ball Screws: High-quality linear guides and ball screws ensure precise movement and reduce play, which is crucial for detailed aluminum work. High Tolerance: CNC routers for aluminum need to operate within tight tolerances to achieve accurate results. Material Handling: Workholding Systems: Secure clamping systems are essential to prevent movement during machining. Consider machines with versatile clamping solutions. Chip Removal: Efficient chip removal systems or vacuums help in maintaining a clean workspace and preventing chip buildup, which can affect machining quality. Frame and Build: Sturdy Construction: A heavy-duty frame is important to minimize vibrations and maintain precision during operation. Rigidity: The machine should have a rigid build to handle the forces involved in aluminum machining. Software and Control: CAD/CAM Software: The machine should be compatible with CAD (Computer-Aided Design) and CAM (Computer-Aided Manufacturing) software for designing and generating toolpaths. User Interface: An intuitive control system is essential for ease of use and efficient operation. Applications: Prototyping: Ideal for creating prototypes and parts in aluminum for various industries. Custom Parts: Used for manufacturing custom components and parts for machinery, automotive, aerospace, and more. Precision Machining: Suitable for high-precision tasks like engraving and detailed cutouts. Considerations: Tooling: Use appropriate tools designed for aluminum, such as end mills and drills with coatings to reduce wear. Speed and Feed Rates: Proper adjustment of speed and feed rates is critical to avoid issues like tool breakage or poor surface finish.
